Waterproof Chip LED COB 30W For Color Lighting ANSI Standard

Negotiable
MOQ
Negotiable
Price
Waterproof Chip LED COB 30W For Color Lighting ANSI Standard
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Led Bead Cob Surface Light Source
Type: 25W Small LES COB LED
Series:: KA Commercial Photography CR, CL, SP Series
Power: 5W/7w/9w/12w
Viewing Angle(°): 120 Degrees
Standard: ANSI Standard
Color Temperature: 1700-8000K
Highlight:

Waterproof Chip LED COB 30W

,

Lighting Chip LED COB 30W

,

ANSI chip led 30w

Basic Infomation
Place of Origin: Zhejiang,China
Brand Name: Kinglux
Certification: CE
Model Number: M25-01L
Payment & Shipping Terms
Payment Terms: L/C, T/T, Western Union, MoneyGram
Product Description

30W Led Bead Cob Surface Light Source For Color Lighting ANSI Standard



  • Features:
  • - 25W small LES COB LED
  • - 2-step/3-step MacAdam ellipse
  • - LESφ14mm
  • - Size: 17.85 x 17.85mm

-Fluorescent powder near-field distribution technology greatly reduces COB temperature;
-ANSI standard 2nd and 3rd order color tolerances are optional;
-High color rendering, high light efficiency, energy-saving, and high saturation color;
- 160LPW@80Ra 3000K 85 ℃;
- 130LPW@90Ra 3000K 85 ℃;
-Certified by LM-80 and EN62471;
-Unique light source spot color design;
-Create a comfortable lighting environment with special lighting





Technical Specifications of Cob Led Chip







Light Royal Blue 445NM – 455NM:
Plants that receive plenty of blue light will have strong, healthy stems and leaves.

Full Spectrum 380-780nm:
Full Spectrum of light, for the Vegetation, Pre-flower, Flower, Ripen/Finish. One lamp for all stages of plant growth.

Warm white 3500K:
3500k lights have more warmer tones to the emitted light, that simulates the color the daylight would be in sunset hours, which promotes higher rates of photosynthesis which in return affects plant flowering.

Cold White 6000K:
6500k give out light that resembles the natural light we see during the day, best used on plants that are only starting to grow or already growing, meaning plants that are in their vegetative stages of growth. Also these bulbs are great for seedlings and even plant cloning.





Advantages of a CoB LED



Using a single LED can result in simpler design and product as well as providing optical advantages for uniform light and efficient optics. Electrical design is simpler because the CoB LED only requires a single two-wire power supply to the entire array of chips.



Part No. Power
(W)
CCT
(K)
CRI TYP
(lm)
VF
(V)
IF
(mA)
Efficacy
(lm/W)
M25-01L
LESφ17mm
30.6 1700 61 4054 34 900 132
1800 90 3483 34 900 114
2200 65 4179 34 900 137
2700 90 4134 34 900 135
3500 90 4200 34 900 137
5600 93 4211 34 900 138
6000 90 4156 34 900 136
8000 90 4112 34 900 134







Why choose us?
1) We provide factory-direct prices.
2) We have our own R&D team, the products can be customized according to your requirements.
3) We provide superior and timely pre-sales advice and after-sales service.
4) W provide service door to door (China to your warehouse), much easy transaction.





FAQ



Q1: Can you accept the sample order?
Yes, we can. we welcome sample order to test and check quality.

Q2: Could I put my logo on it?
Of course. The logo can be made according to your requirements once you reached our MOQ.

Q3: What's your packaging?
We have a color box and a carton. Welcome to customize if you need it.

Q4: What's your lead time?
3-7 days for the sample orders in the stock. 25-30 days for mass production.
